• Towable Boom Lift product image 1 - Mulciber Industries
  • Towable Boom Lift product image 2 - Mulciber Industries
1 2

Towable Boom Lift

Towable Boom Lift

$100,000.00
Height and Capacity
View full details
Equipment Overview
Equipment Type
Towable Boom Lift
Lift Category
Boom Lifts
Variant Specifications
Performance
Height and Capacity Lifting Height Capacity Working Radius
10 m Height / 200 kg Capacity 10 m 200 kg 5.5 m
12 m Height / 200 kg Capacity / 6.5 m Working Radius 12 m 200 kg 6.5 m
12 m Height / 200 kg Capacity / 7.8 m Working Radius 12 m 200 kg 7.8 m
14 m Height / 200 kg Capacity 14 m 200 kg 8.5 m
16 m Height / 200 kg Capacity 16 m 200 kg 10.5 m
18 m Height / 200 kg Capacity / 10.5 m Working Radius 18 m 200 kg 10.5 m
18 m Height / 200 kg Capacity / 11 m Working Radius 18 m 200 kg 11 m
19.8 m Height / 200 kg Capacity 19.8 m 200 kg 11 m
Dimensions & Power
Height and Capacity Platform Size Overall / Stowed Size Machine Weight Power / Engine / Battery
10 m Height / 200 kg Capacity 900 x 700 mm 6300 x 1680 x 2100 mm 1700 kg Contact Mulciber for configuration details
12 m Height / 200 kg Capacity / 6.5 m Working Radius 900 x 700 mm 7300 x 1680 x 2100 mm 2000 kg Contact Mulciber for configuration details
12 m Height / 200 kg Capacity / 7.8 m Working Radius 900 x 700 mm 5800 x 1680 x 2100 mm 2100 kg Contact Mulciber for configuration details
14 m Height / 200 kg Capacity 900 x 700 mm 6800 x 1680 x 2100 mm 2400 kg Contact Mulciber for configuration details
16 m Height / 200 kg Capacity 900 x 700 mm 6900 x 1680 x 2200 mm 2600 kg Contact Mulciber for configuration details
18 m Height / 200 kg Capacity / 10.5 m Working Radius 900 x 700 mm 6600 x 1800 x 2250 mm 4100 kg Contact Mulciber for configuration details
18 m Height / 200 kg Capacity / 11 m Working Radius 900 x 700 mm 7600 x 1800 x 2250 mm 4300 kg Contact Mulciber for configuration details
19.8 m Height / 200 kg Capacity 900 x 700 mm 6900 x 1900 x 2250 mm 4500 kg Contact Mulciber for configuration details
